SolaX TB-HS51 5,1 kWh high voltage LFP battery module

The SolaX TB-HS51 5,1 kWh high-voltage battery module This is a stackable LFP module for the modular TSYS-HS51 storage system. With a module capacity of 5,1 kWh, IP66 protection, and over 6.000 cycles, it supports long-lasting storage solutions for both indoor and outdoor applications. The 46 kg module is combined with a compatible BMS unit and an approved SolaX inverter to form a complete high-voltage system, ensuring predictable future storage expansion.

Delivery

1× SolaX TB-HS51 5,1 kWh battery module
Not included: BMS, socket, series box, inverter and external installation components

Produktvorteile

-- 5,1 kWh per module. The storage capacity can be scaled within the TSYS-HS51 system limits.

-- IP66 enclosure. Designed for approved indoor and outdoor installations.

-- Stackable concept. Facilitates a modular and space-saving system design.

Compatibility

For use with the SolaX TSYS-HS51 system with a compatible BMS unit and approved SolaX inverters. This module is not a standalone storage device.

Technical information

-- Module capacity: 5,1 kWh
-- Battery type: LFP
-- Dimensions: 600 × 168 × 376 mm
-- Net weight: 46 kg
-- Protection class: IP66
-- Cycles: more than 6.000

Matching accessories and related products

Alternative high-voltage battery storage systems from our product range. These Huawei models are not expansion modules for SolaX; inverter approvals and system components differ.

HUAWEI LUNA2000-5-E0 PV battery module
HUAWEI LUNA2000-7-E1 PV battery module
HUAWEI LUNA2000-5-S0 battery storage
HUAWEI LUNA2000-10-S0 battery storage

Why Mini Power

Mini Power supplies the SolaX TB-HS51 battery module with a unique MPN assignment and transparent differentiation from the BMS, socket, and complete system from our remote warehouse. We support you in planning the number of modules and their assignment to the inverter, ensuring that capacity, voltage, and system components are correctly matched. This allows you to compare the model, generation, and system requirements with your plans before purchasing and ask specific questions about your intended system.

Frequently asked questions

-- Is the BMS included?

No. This position includes only one TB-HS51 battery module.

-- Can the module be installed externally?

The module is IP66 protected; however, the complete installation must still comply with the manufacturer's and site specifications.
