GoodWe GW20K-ETA-G20 20 kW Hybrid Inverter

The GoodWe GW20K-ETA-G20 20 kW Hybrid Inverter This is a three-phase ETA unit for the modular GoodWe ESA storage system. Four MPP trackers support the planning of larger PV generators. Communication is facilitated by WLAN, LAN, Bluetooth, and RS485. The NBG0020-06-00P model has an IP66 protection rating; battery, metering, and backup components are added as needed for specific projects. This makes the unit suitable for professionally planned residential complexes and smaller commercial projects.

Delivery

1× GoodWe GW20K-ETA-G20 Hybrid Inverter NBG0020-06-00P
1x matching base
Not included: Battery storage, smart meter and backup components

Produktvorteile

-- 20 kW power class. The inverter is designed for larger private and small commercial PV storage projects.

-- Four MPP trackers. Multiple PV sub-areas can be flexibly planned within the manufacturer's limits.

-- Modular ESA platform. The system can be built using approved battery modules and expansion components.

Compatibility

The GW20K-ETA-G20 is designed for the GoodWe ESA platform and approved BAT-D high-voltage batteries. Smart meters, additional battery towers, expansion kits, and optional backup components must be selected based on the current GoodWe system design and firmware approvals.

Technical information

-- AC rated power: 20 kW
-- Phases: 3
-- MPP tracker: 4
-- Maximum DC voltage: 1.000 V
-- Communication: WLAN, LAN, Bluetooth, RS485
-- Protection class: IP66
-- Manufacturer MPN: NBG0020-06-00P

Matching accessories and related products

Alternative three-phase hybrid inverters from our product range. Manufacturer, power output, and battery platform differ; the devices are not directly interchangeable system components.

HUAWEI SUN2000-12K-MB0 hybrid inverter
HUAWEI SUN2000-15K-MB0 hybrid inverter
HUAWEI SUN2000-20K-MB0 hybrid inverter
HUAWEI SUN2000-25K-MB0 hybrid inverter

Why Mini Power

Mini Power offers the GoodWe GW20K-ETA-G20 with complete model and MPN identification. This prevents confusion with similarly named ET or EHA variants. We clearly identify separately sourced storage and backup components and recommend a complete system check by a qualified technician. Shipping is from our remote warehouse; therefore, delivery time and project deadline should be coordinated before installation. This allows you to precisely match the model, installation location, and required components with your existing or planned system before purchasing.

Frequently asked questions

Does it include a battery storage system?

No. The compatible GoodWe BAT-D battery modules are selected separately.

Does the version come with a base?

Yes, the supplier position NBG0020-06-00P includes the base.

Can the device be connected without a professional?

No. Design, grid connection and commissioning require a qualified electrical contractor.
