GoodWe GW15K-ETA-G20 15 kW Hybrid Inverter

The GoodWe GW15K-ETA-G20 15 kW Hybrid Inverter This is the three-phase ETA unit of the modular GoodWe ESA storage system. Four MPP trackers support flexible PV system design, while WLAN, LAN, Bluetooth, and RS485 enable system communication. The NBG0015-04-00P model has an IP66 protection rating. Battery, metering system, and backup components are added on a project-specific basis. This makes the unit suitable for professionally planned residential complexes and smaller commercial projects.

Delivery

1× GoodWe GW15K-ETA-G20 Hybrid Inverter NBG0015-04-00P
1x matching base
Not included: Battery storage, smart meter and backup components

Produktvorteile

-- Four MPP trackers. Different PV sub-areas can be recorded separately within the approved design.

-- ESA system integration. The inverter is designed for the modular GoodWe ESA storage system.

-- Integrated communication. WLAN, LAN, Bluetooth and RS485 support commissioning and system monitoring.

Compatibility

The GW15K-ETA-G20 is designed for the GoodWe ESA platform and the approved BAT-D high-voltage batteries. Additional towers, smart meters, STS and backup components, and their firmware versions must be checked on a project-specific basis using the current GoodWe documentation.

Technical information

-- AC rated power: 15 kW
-- Phases: 3
-- MPP tracker: 4
-- Maximum DC voltage: 1.000 V
-- Communication: WLAN, LAN, Bluetooth, RS485
-- Protection class: IP66
-- Manufacturer MPN: NBG0015-04-00P

Matching accessories and related products

Alternative three-phase hybrid inverters from our product range. Manufacturer, power output, and battery platform differ; the devices are not directly interchangeable system components.

HUAWEI SUN2000-12K-MB0 hybrid inverter
HUAWEI SUN2000-15K-MB0 hybrid inverter
HUAWEI SUN2000-20K-MB0 hybrid inverter
HUAWEI SUN2000-25K-MB0 hybrid inverter

Why Mini Power

At Mini Power, the GoodWe GW15K-ETA-G20 is clearly identified by model and manufacturer MPN. We separate the inverter, battery, and optional system components to ensure project planning remains transparent. Before ordering, a qualified professional should confirm the required power output, battery voltage, measurement specifications, backup requirements, and grid specifications. Shipping is from our remote warehouse; therefore, the displayed delivery time must be factored into project scheduling. This allows you to precisely compare the model, installation location, and required components with your existing or planned system before purchasing.

Frequently asked questions

Does it include a battery?

No. Suitable GoodWe BAT-D battery modules are configured separately.

-- Is the base included in the delivery?

Yes, the version NBG0015-04-00P listed in the supplier list includes the base.

Who is allowed to install the device?

Planning, connection and commissioning should be handled by a qualified electrical or solar specialist company.
